Sanwa ดิจิตอล มัลติมิเตอร์ PC-Link รุ่น PC710

6000&9999 counts
Dual display shows voltage/current and its frequency, and AC components and DC components of voltage/current
EF(Electric Field)detection to indicate signal strength of electric field which surrounds current carrying conductors
Capture (peak hold), Interval:1ms
MAX/MIN/AVG recording mode
K type thermocouple temperature measurement -50℃ ～ 1000℃
Conductance measurement
Auto power save (17min.) (cancelable)

รายละเอียดสินค้า

PC710	Measuring range	Best accuracy	Resolusion	Input impedance
DCV	60m/600m/9.999/99.99/600V	±(0.06%+2)	0.01mV	10MΩ
ACV	60m/600m/9.999/99.99/600V	±(0.5%+3)	0.01mV	10MΩ
DCA	600μ/6000μ/60m/600m/6/10A	±(0.2%+4)	0.1μA
ACA	600μ/6000μ/60m/600m/6/10A	±(0.6%+3)	0.1μA
Resistance	600/6k/60k/600k/6M/60MΩ	±(0.1%+3)	0.1Ω
Conductance	99.99S	±(0.8%+10)	0.01nS
Capacitance	60n/600n/6μ/60μ/600μ/6m/25mF	±(0.8%+3）※	0.01nF
Temperature	-50～1000°C(thermocouple K type)	±(0.3%+2)	1°C
Frequency	15Hz～50kHz	±(0.04%+4)	0.01Hz
Logic frequency	5Hz～1MHz	±(0.03%+4)	0.001Hz
Duty cycle	0%～100%	±(3d/kHz+2)
Continuity	Buzzer sounds at between 20Ω and 300Ω Open voltage:approx.1.2V
Diode test	Open voltage : approx.3.5V
Electric field sensing (EF)	At the standard sensing voltage of about 20V or more,the bar graph and intermittent sound vary in 5 steps

Display	numeral display 9999 & 6000, bar graph 41 segments
Sampling rate	5 times/sec. 60 teims/sec.for bar graph
Bandwidth	V:40Hz～3kHz 3kHz～20kHz（below 99.99V） A:40Hz～1kHz
Fuse	11A/1000V IR20kA Φ10× 38 mm 0.4A/1000V IR30kA Φ 6.3× 32 mm
Battery	6F22(9V)x1
Battery life	Approx. 60h (manganese battery) at DCV range
Size/Mass	H184×W86×D52mm/Approx.430g（including holster)
Safety	IEC61010 CAT.Ⅲ600V
